HOTRONIX® FUSION IQ™ HEAT PRESS

Technologically advanced and easy to use, the Fusion operates as either a swing-away or draw heat press, fitting in almost any workspace and giving you two options for heat-free layout. With a 16″ x 20″ platen (optional additional platens available), touch screen controller, and digital time, temperature and pressure readout, the technologically advanced Fusion makes heat printing a breeze.

$2,250.00

Heat Press Tech Specs

Technical Specifications

Features

  • Fusion IQ™ controller with larger, higher-resolution touch screen
  • Access reports, manage users, and troubleshoot issues online
  • Self-diagnostics for troubleshooting and maintenance
  • 3/4 inch heated upper platen with non-stick coating
  • Threadability™ — Load the garment once and print, front, back, and sides
  • Optional smaller interchangeable platens (ships with 16″ x 20″ platen)
  • Live digital time, temperature, and pressure readout.
  • Multiple time settings
  • Production cycle counter
  • 8 Language settings
  • Electrical Options:
    120 v; 15 amps; 1800 w
    240 v; 15 amps; 3500 w
  • UL/ULC/CE/RoHS approved.
  • Temperature range 32° – 430°F
  • °F or °C available.
  • Proudly made in the USA.
  • Actual Weight: 137 lbs
  • Shipping Weight: 150 lbs
  • Dimensions: 32″ x 18″ x 20″
  • Shipping Dimensions: 37″ x 25″ x 24″

Hotronix Premier Warranty

  • Lifetime Warranty on Heating Element
  • 5 yr on Framework
  • 2 yr on Circuit board
  • 1 yr parts/labor
